C0-1000 | CO-630B | HYQ-500B | HM-400 | ||||
|
|
|
| ||||
Split hydraulic clamp ●It is specially designed for inside and outside power transmission and distribution project,various kinds of connecting terminals,overhead and underground cabling. ●Crimping high voltage cable sleeve,wire grips,un-insulated terminals,hexagon terminals.Crimped part tight and uneasy to break out in good conductivity. ●Standard seven sets of die assembling. ●Dies could be ordered and available in any sizes. ●The oil pipe coupler fitted with PT 3/8 thread. ●To be worked with pedal pump,manual pump and electric driven hydraulic pump. | |||||||
Model | Range of Application | Crimping force | Stroke | Standard dies | Weight | Packaging & Size | Package |
Al,Cu Terminal Crimping | |||||||
C0-1000 | 300-800mm²(Al Terminal) | 60 ton | 24mm | 400,500,630,800,1000mm² | 32Kg | 755x130x230mm | Carton |
C0-630B | 50-630mm² | 35 ton | 26mm | 150,185,240,300400,500,630mm² | 17.5Kg | 380x130x70mm | Steel case |
HYQ-500B | 50-500mm² | 22 ton | 22mm | 50,70,95,120,150,185,240,300,400,500mm² | 20Kg | Steel case | |
HM-400 | 35-300mm²(Al Terminal) | 16 ton | 20mm | 50,70,95,120,150,185,240,300,400mm² | 9Kg | 355x90x155mm | Steel case |
C0-630A | EP-510H | EP-410H | CYO-400B | ||||
|
|
|
| ||||
●The compression pliers are designed for hydraulic crimping on power cable and wire. ●The crimped conductor is tested in high conductivity and close contact so that its uneasy to break out and turn hot. ●Open cut design for convenient operation. ●Standard ten sets of die assembling. ●The oil pipe coupler fitted with PT 3/8 thread ●To be worked with pedal pump,manual pump and electric driven hydraulic pump. | |||||||
Model | Range of Application | Crimping force | Stroke | Standard dies | Weight | Packaging & Size | Package |
Al,Cu Terminal Crimping | |||||||
CO-630A | 150-630mm² | 30 ton | 25mm | 150,185,240,300400,500,600mm² | 25Kg | Carton | |
EP-510H | 35-300mm²(Al Terminal) 50-400mm²(Cu Terminal） | 13 ton | 38mm | 50,70,95,120,150,185,240,300,400mm² | 5.6Kg | 355x90x155mm | Steel case |
EP-410H | 16-300mm²(Al Terminal) 50-300mm²(Cu Terminal) | 12 ton | 30mm | 35,50,70,95,120,150,185,240,300mm² | 4.8Kg | 355x90x155mm | Steel case |
CYO-400B | 16-400mm²(Al Terminal) 50-400mm²(Cu Terminal) | 12 ton | 32mm | 50,70,95,120,150,185,240,300,400mm² | 5Kg | 355x90x155mm | Steel case |
