TC-602 | TC-603 | TC-604 | TC-1002 |
Wire range:14mm² | Wire range:14mm² | Wire range:14mm² | Wire range:14mm² |
Rated current/Voltage:60A/600V | Rated current/Voltage:60A/600V | Rated current/Voltage:60A/600V | Rated current/Voltage:100A/600V |
|
|
|
|
TC-1003 | TC-1004 | TC-1503 | TC-1504 |
Wire range:22mm² | Wire range:22mm² | Wire range:60mm² | Wire range:60mm² |
Rated current/Voltage:100A/600V | Rated current/Voltage:100A/600V | Rated current/Voltage:150A/600V | Rated current/Voltage:150A/600V |
|
|
|
|
TC-2003 | TC-2004 | TC-3003 | TC-3004 |
Wire range:100mm² | Wire range:100mm² | Wire range:150mm² | Wire range:150mm² |
Rated current/Voltage:200A/600V | Rated current/Voltage:200A/600V | Rated current/Voltage:300A/600V | Rated current/Voltage:300A/600V |
|
|
|
|
TC-4003 | TC-4004 | TC-5003 | TC-5004 |
Wire range:200mm² | Wire range:200mm² | Wire range:250mm² | Wire range:250mm² |
Rated current/Voltage:400A/600V | Rated current/Voltage:400A/600V | Rated current/Voltage:500A/600V | Rated current/Voltage:500A/600V |
|
| ||
TC-6003 | TC-6004 | ||
Wire range:300mm² | Wire range:300mm² | ||
Rated current/Voltage:600A/600V | Rated current/Voltage:600A/660V |
