CELE-32 earth leakage circuit breakers are mainly applied to the AC 50Hz/60Hz circuit rated 240V and 32A or below, They have the electric leakage(electric shock), overload, short circuit and so on protection functions.
◆Application
CELE-32 earth leakage circuit breakers are mainly applied to the AC 50Hz/60Hz circuit rated 240V and 32A or below, They have the electric leakage(electric shock), overload, short circuit and so on protection functions.The over voltage protection function can also be provided upon requirements. They are mainly used to protect the building illumination and power distribution system.
◆Specifications
Rated | Rated Current (A) | I△n | I△no | Breaking Times(S) | 1△ mA(A) | |||
I△n | 2I△n | 0.25A | 500A | |||||
240 | 6,10,16,20,25,32 | 30,100 | 15,50 | 0.1 | 0.05 | 0.04 | 0.04 | 3000 |
◆Notices
1. Leakage protection function of RCBO is tested and adjusted by the manufacture, users can not open the products at random during usage.
2. After using RCBO for a certain time(normally one month), test button should be pressed once in a state of making the circuit to check whether the function of RCBO is normal and reliable(press test button once, the RcBO can break off once).if abnormal, it should be unloaded and sent to the manufacturer to repair.
3. RCBO can not be wetted or soaked by rain, snow or water during the course or transportation storage and usage.
◆Characteristic Curve
