Cylindrical fuse link with cylindrical contact caps is designed for protecting electrical distrbuting in rated current up to 125A.
◆Feature
Cylindrical fuse link with cylindrical contact caps is designed for protecting electrical distrbuting in rated current up to 125A.Against damage due to overload and short circuit.Fuse link with the striker is supplied for the purpose of protecting against motor single phasing operation when fitted in fuse-isolators.This product conforms with I EC60269 and VDE0636 standards.
◆Specifications
Size(mm) | Rated Current(A) |
8.5×31.5 | 0.5,1,2,4,6,10,16,20,25 |
10×38 | 0.5,1,2,4,6,10,16,20,25,32 |
14×51 | 1,2,4,6,10,16,20,25,32,40,50,63 |
22×58 | 2,4,6,8,10,16,20,25,32,40,50,63,80,100,125 |
30×58 | 63,80,100,125 |
