◆Specifications
CEK5 cam starter is mainly used to start,stop,forward or backward directly three-phase asynchronous electric motor with AC 50Hz,voltage up to 500V and capacity up to 7.5KW.It can also be used for changeover from one kind of circuit to another.
◆Specifications
| TypeT | Mark | Rated Current | Motor Control | Electrica Llife | Mechanical Life | Frequency of | Applications | Position of Level |
CEK5-15A | I-O | 15 | 5.5 | 100000 | 250000 | 200 | ON-OFF Switching | 0-60 |
CEK5-30A | 30 | 10 | ||||||
CEK5-15N | I-O-I | 15 | 5.5 | Forward Reverse | 60-0-60 | |||
CEK5-30N | 30 | 10 | ||||||
CEK5-15P/3 | I-O-II | 15 | 5.5 | For 3 phase 2 wire | 60-0-60 | |||
CEK5-30P/3 | 30 | 10 | ||||||
CEK5-63A | I-O | 63 | 22 | 80000 | 200000 | 180 | ON-OFF Switching | 0-60 |
CEK5-100A | 100 | 30 | ||||||
CEK5-63N | I-O-I | 63 | 22 | Forward Reverse | 60-0-60 | |||
CEK5-100N | 100 | 30 | ||||||
CEK5-63P/4 | I-O-II | 63 | 22 | For 3 phase 2 wire | 60-0-60 | |||
CEK5-100P/4 | 100 | 30 |
