CECP2 DC Contactor

for motor control,from 6 to 95A(AC-3)for the control of distribution circuits,from 16 to 125A(AC-1)Control circuit DC

◆Application

for motor control,from 6 to 95A(AC-3)for the control of distribution circuits,from 16 to 125A(AC-1)Control circuit DC

◆Specifications

Basic Reference Complete With Code Indicating Control Circuit Voltage	Standard Power Ratings of 3-phase Motors 50/60Hz In Category AC-3						Rated Operating Current		Rated Non-conductive Voltage (A)
Fixing	220V 230V KW	380V 440W KW	415V KW	440V KW	500V KW	660V 690V KW	AC-3 up to 440V A	AC-1 θ≤ 40C A	Rated Non-conductive Voltage (A)
CECP2-0910 CECP2-0901	2.2	4	4	4	4	4	9	16	660
CECP2-1210 CECP2-1201	3	5.5	5.5	5.5	7.5	7.5	12	25	660
CECP2-1810 CECP2-1801	4	7.5	9	9	10	10	18	32	660
CEC2-2510 CEC2-2501	5.5	11	11	11	15	15	25	40	660
CECP2-3210 CECP2-3201	7.5	15	15	15	18.5	18.5	32	50	660
CECP2-4011	11	18.5	22	22	22	30	40	60	660
CECP2-5011	15	22	25	30	30	33	55	80	660
CECP2-6511	18.5	30	37	37	37	37	65	80	660
CECP2-8011	22	37	45	45	55	45	80	125	660
