The series of UPS is new products applied the world latest technology and designed specialy for the personal computer,intergrating the functions of AC regulators.....
◆Application
The series of UPS is new products applied the world latest technology and designed specialy for the personal computer,intergrating the functions of AC regulators,high-speed reserve power supply and wave absorption,have the characteristics of compact size,full function,high efficiency and quality,easy use etc.And their remarkable advantage of self-protection not only provide you uninterrupted power,also improve greatly the quality of power supply.Hence,decrease the bad effect to computer because of the bad quality of power supply.
◆Specifications
Model | UPS-H | |||
Power | D500 | F500/F1000 | HSO0/H1000 | K780S/K1280S |
Input Voltage | 220V+10% | 180-260V | 170-265V | 165-280V |
Direct Supply Time | 7min | 10-15min | Long delay time unit | |
Frequency of Direct Supply | 50Hz±10% | |||
Direct Output Voltage | 220V±10% | |||
Charging Time of Battery | Receive 90%within 8 hours | |||
Inverted Output Voltage | 220V±10%Square wave | |||
Frequency of Inverted Output | 50Hz±1% | |||
Service Conditons | Ambient temperature 0-40℃ relative humidity:<90% | |||
◆Specifications
Model | UPS-L | ||||
Power | 500VA/350W | 650VA/420W | 1000VA/650W | 1200VA/750W | |
Input | Voltage Range | 145VAC-285V AC | |||
Frequency | 50/60Hz+2.5% | ||||
Output | Voltage Range | 220VAC+5% | |||
Frequency | 50/60Hz+1% | ||||
Waveform | Simulated sine waveform | ||||
Transfer Time | 4ms(Typica I) | ||||
Battery | Type | Sealed,maintenance-free lead acid | |||
Capacity | 12V 7AH×1 | ||||
Backup Time | Over 8 minutes if use for one PC with a 17"monitor | ||||
Recharge Time | 8 hours to 90% of full capacity | ||||
Comn munication | RU PS2000 | Option:RS232,RJ45/11 Port | |||
Protection | Output overload protection | ||||
Output short circuit protection | |||||
Battery over discharge protection | |||||
Thunder protection IEEE-587A | |||||
Audible alarm | Power-off.Beeping sound every 4 seconds | ||||
Voltage-lack:Beeping sound every 1 second | |||||
Failure of battery use up:continuous beeping | |||||
Environment | Temperature/ | -5℃-40℃，10%RH-90%RH | |||
Noise | 45<dB(A)(at one meter) | ||||
